King Innovation

King Innovation Medium Wire Connectors (2 ct.) | 20230

SKU
20230
HLSG SKU:
MMM20230
Free Shipping on Orders over $149

Waterproof and corrosion-proof, this DryConn wire connector from King Innovation features a snap-fit lid for maximum strain relief on splices. Included is a red and yellow nut that allows you to make connections with a cushion-grip wire connector for enhanced comfort.

  • 2 connectors per order
  • Max Voltage: 600 V building wire, 1000 V signs and luminaries
  • One-step installation; no pre-twisting wires necessary
  • Can be used in direct burial applications
  • UV and impact resistant
Sales Price $3.75 Our Price $6.95 You save 46%

Installation Instructions

  1. Important! Shut off the power before installing or removing the connector.
  2. Strip wires 5/8 in.
  3. Hold stripped wires together with ends of insulation even, leading stranded wires slightly.
  4. Align any frayed strands or conductors.
  5. Firmly push wires into twist-on connector and screw connector clockwise onto wire until tight.
  6. Insert the splice to the bottom of the sealant filled tube.
  7. Position wires into wire channels.
  8. Wipe any sealant around opening and conductors.
  9. Close lid until latch is secure.

Pro Tip: If you're having difficulty getting the twist-on connector down into the tube when using small gauge wires, we recommend using a thin, non-conducive object to push the connector to the bottom of the tube. Upon removal of the object, wipe sealant in and around the opening created by the non-conducive object.

Warranty

One (1) year from the date of purchase

Quick Facts

  • Length: 3.7 in.
  • Width: 1.5 in.
  • Wire Type: Copper/Copper
  • Wire Range: #22 - #8 AWG
  • Temperature Rating: 221°F
  • Silicone Sealant Temperature: -45°F to 400°F
  • UL Listed

Downloads

Specifications (303.14 kB)
More Information
Brand King Innovation
Type Wire Connectors
Max Voltage 600V Buliding, 1000V Signs or Luminaries
Temperature Range -45 - 400°F
Temperature Rating 221°F
Wire Range Min #22/Max #8
Warranty 1 Year
